All-In-One 1-Inch Large CMOS Mini Camera Drone
DJI Mini 5 Pro – Pro in Mini
DJI Mini 5 Pro features a 1-inch CMOS camera, nightscape omnidirectional obstacle sensing [1], a gimbal with 225° of flexible rotation, and upgraded ActiveTrack 360°, all packed into its signature lightweight body. With performance on par with flagship drones, it captures life’s beautiful moments and preserves your treasured memories in stunning detail.
1-Inch Large CMOS Camera
Nightscape Omnidirectional Obstacle Sensing [1]
True Vertical Shooting and 225° Flexible Gimbal Rotation
Upgraded ActiveTrack 360°
Lightweight and Portable
Extended Battery Life [2]
Go Big with Mini
Mini 5 Pro features an ultra-light, palm-sized foldable design that slips easily into a backpack or pocket. It is C0-certified [3], enabling hassle-free flights across most EU member states. With 42GB of internal storage, footage can be saved directly, ensuring uninterrupted flight enjoyment.
1-Inch CMOS Sensor, Capture Like a Pro
With a 50MP 1-inch CMOS sensor and f/1.8 aperture, Mini 5 Pro captures rich details and clean low-light shots. Compact in size, it delivers pro-level imaging.
Mini 5 Pro integrates a 1-inch CMOS sensor, supporting 4K/60fps HDR video recording with up to 14 stops of dynamic range for cinematic visuals [4]. This large sensor, enhanced by the new image-processing technology and intelligent algorithms [5], preserves even minute details in low-light conditions such as sunsets and nightscapes, delivering shots that are simply, effortlessly breathtaking. With the 48mm Med-Tele mode, subjects stand out more prominently in the frame, while portrait optimization algorithms [6] capture every expression with remarkable clarity.
Med-Tele Mode
With 2x zoom, the new 48mm Med-Tele mode now offers higher image resolution than the digital zoom on previous DJI Mini Pro series. Subjects stand out with greater texture, adding depth to your aerial shots.
Portrait Optimization [6]
Featuring DJI’s portrait optimization technology [6], DJI Mini 5 Pro enhances portraits’ brightness, contrast, and skin tones. Whether it’s a group shot or candid moment, portraits look naturally radiant with more vivid expressions. The 48mm Med-Tele mode further highlights subjects with true-to-life vibrance.
Compact, Yet Cinematic
4K/60fps HDR Video
The HDR video mode offers up to 14 stops of dynamic range [4], capturing cinematic footage in high-contrast scenes, such as detailed views of cloud textures and other elements during sunrise and sunset.
4K/120fps Slow-Motion Video
Mini 5 Pro supports slow-motion video recording at 4K/120fps, ensuring stunning clarity and fluidity with high resolution and frame rates. Dynamic details come to life, adding impact to footage and providing greater creative flexibility in post-production.
10-bit Video and High ISO Performance
Even in normal color mode, Mini 5 Pro can record 10-bit video using H.265 encoding, delivering refined color performance and greater flexibility in post, with the maximum ISO raised to 12800. In D-Log M and HLG color modes, the maximum ISO is raised to 3200, allowing for greater brightness and more details in urban night scenes.
True Vertical Shooting and 225° Flexible Gimbal Rotation
Mini 5 Pro supports wide-angle roll rotation and true vertical shooting, bringing greater freedom and possibilities to camera movement. Both manual control and intelligent modes provide greater flexibility in camera angles and flight routes, allowing for more creative compositions. Even when shooting upward at tall buildings or from challenging angles, unique viewpoints that were once difficult to capture can now be achieved with ease, fully unlocking creative inspiration.
225° Gimbal Rotation for Dynamic Camera Movement
With 225° roll rotation, the gimbal enables flexible and dynamic camera movement. Paired with intelligent modes like QuickShot Rotate, Timelapse, Spotlight, and Waypoint Flight, capturing creative rotating footage is now easy.
True Vertical Shooting for Instant Sharing
Excellent for skyscrapers, waterfalls, and vibrant city scenes, instantly shoot vertical videos and photos and share. No cropping needed. Every photo and video is ready for social media, filling the screen with vibrant, full-frame brilliance.
Confident Flight With Nightscape Omnidirectional Obstacle Sensing
Mini 5 Pro features a forward-facing LiDAR and multiple vision sensors for nightscape omnidirectional obstacle sensing [1], making return-to-home safer. In city nightscapes, it actively detects and avoids obstacles along flight and return paths for worry-free night flying. With sufficient light, it can memorize flight routes [7], enabling safe takeoff and return even without satellite signal.
Omnidirectional Vision Sensing System
Equipped with a forward-facing LiDAR, Mini 5 Pro features fisheye lenses on the front and rear for sensing forward, backward, left, right, and upward. The bottom is fitted with binocular lenses and a 3D infrared sensor, enabling omnidirectional obstacle sensing.
Nightscape Omnidirectional Obstacle Sensing [1]
Provides robust safety for night photography, allowing you to create with confidence and efficiency.
Nighttime RTH
With the forward-facing LiDAR, Mini 5 Pro detects obstacles like tall buildings even in low-light conditions and intelligently maneuvers upward [7], ensuring safer returns during nighttime flights.
Non-GNSS RTH
Powered by real-time vision positioning and map construction technologies, Mini 5 Pro memorizes flight paths when adequate lighting is available. This ensures a safe return [7] even when taking off from locations without satellite signals, such as balconies.
Dual-Band GNSS
With L1 + L5 dual-band GNSS, Mini 5 Pro connects to more satellites, for improved signal stability and precise positioning.
Upgraded ActiveTrack 360°
Mini 5 Pro captures every highlight, wherever you are. The upgraded ActiveTrack 360° offers customizable tracking in various scenarios, and features more stable and safer tracking performance [8].
Multi-Scenario Tracking:
Mini 5 Pro detects sports scenarios and automatically selects Cycling or Standard mode for optimal framing and tracking. In Standard mode, the drone follows your path in real time, maintaining steady altitude and distance. In Cycling mode, it reacts quickly to turns and speed changes to keep you locked in and perfectly framed.
Smoother and Safer Tracking:
Tracking performance has been enhanced to balance speed, agility, and safety. In open areas, the maximum tracking speed has been raised to 15 m/s [9] for quicker response. In complex environments, the drone can switch to rear tracking mode, steadily keeping the subject in focus and enabling creative freedom with confidence.
Intelligent Modes
MasterShots
Provides high-level camera movement templates according to portrait, close-up, and long-distance shooting needs.
QuickShots
Supports various modes such as QuickShot Rotate, Dronie, Circle, Helix, Rocket, Boomerang, and Asteroid, allowing you to easily shoot stylish short films.
Free Panorama
Supports Free Panorama, letting you create seamless panoramic shots by stitching together multiple images with a manually selected subject or area.
Off-State QuickTransfer
Mini 5 Pro supports remote wake-up via the DJI Fly app within Bluetooth range. Without taking out the drone or remote controller [10], files can be transferred at up to 100 MB/s [11] via Wi-Fi 6. Even when switching to other apps, the DJI Fly app continues downloading in the background.
Specs
Aircraft
Takeoff Weight: 249.9 g
Product weight may vary due to differences in batch materials and other factors. The actual weight is approximately 249.9 g ± 4 g and is subject to the actual product. Before flying with the Intelligent Flight Battery or the Intelligent Flight Battery Plus, check and comply with local laws and regulations to confirm whether registration or an exam is required.
The Intelligent Flight Battery Plus is not sold in Europe.
Dimensions
Unfolded (with propellers): 255×181×91 mm (L×W×H)
Max Ascent Speed
5 m/s (N Mode)
5 m/s (C Mode)
Max Descent Speed
6 m/s (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery)
5 m/s (N Mode)
5 m/s (C Mode)* The Intelligent Flight Battery Plus is not sold in Europe.
Max Horizontal Speed
18 m/s* (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery)
15 m/s*** (tracking status)* Measured in a wind tunnel test environment when taking off from an altitude of 0 meter and ascending vertically to a height of 1.5 meters above the ground in Sport mode, and is for reference only. Always pay attention to reminders on the camera view during your flight.
** The Intelligent Flight Battery Plus is not sold in Europe.
*** Measured in an open, windless test environment with the drone taking off from an altitude of 0 meters.
Max Takeoff Altitude
4500 m (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)* The Intelligent Flight Battery Plus is not sold in Europe.
Max Flight Time
36 minutes (using DJI Mini 5 Pro Intelligent Flight Battery)
Measured by the aircraft flying forward at a constant speed of 21.6 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, until forced landing due to low voltage. Data is for reference only. Always pay attention to reminders in the app during your flight.
52 minutes (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)
Measured by the aircraft flying forward at a constant speed of 25.2 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, until forced landing due to low voltage. Data is for reference only. Always pay attention to reminders in the app during your flight.
* The Intelligent Flight Battery Plus is not sold in Europe.
Typical Flight Time
33 minutes (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)Measured at sea level in a breezy environment, with the aircraft taking off with a fully charged battery, Obstacle Avoidance Action set to Brake, and the camera set to record at 4K/60fps. After takeoff, the aircraft ascends to 120 m and flies forward 1 km at 15 m/s before recording begins (about 15 minutes of recording with the Intelligent Flight Battery, and about 20 minutes with the Intelligent Flight Battery Plus). During recording, the aircraft adjusts gimbal movements and its flight position at speeds of up to 10 m/s over a total distance of approximately 2 km, while hovering for the remaining time. The aircraft hovers until a RTH reminder appears, then initiates auto RTH and completes a safe landing. Data is for reference only. Always pay attention to reminders in the app during your flight.
* The Intelligent Flight Battery Plus is not sold in Europe.
Max Flight Distance
32 km (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)Measured by the aircraft flying forward at a constant speed of 39.6 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, until forced landing due to low voltage. Data is for reference only. Always pay attention to reminders in the app during your flight.
* The Intelligent Flight Battery Plus is not sold in Europe.
Max Wind Speed Resistance
Max Pitch Angle
Operating Temperature
Global Navigation Satellite System
Hovering Accuracy Range
±0.1 m (with vision positioning)
±0.5 m (with satellite positioning)Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with satellite positioning)
Internal Storage
Class
Camera
Image Sensor
Lens
Format Equivalent: 24 mm
Aperture: f/1.8
Focus: 0.5 m to ∞
ISO Range
Normal:
100-12800 (Normal)
100-3200 (D-Log M)
100-3200 (HLG)
Slow Motion:
100-6400 (Normal)
100-3200 (D-Log M)
100-3200 (HLG)Photo
100-6400 (12 MP)
100-3200 (50 MP)
Shutter Speed
50MP Photo: 1/8000-2 s
Max Image Size
Still Photography Modes
Burst Shooting: 12 MP, 3/5/7 frames; 50 MP, 3/5 frames
Automatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames; 50 MP, 3/5 frames at 0.7 EV step
Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s; 50 MP, 5/7/10/15/20/30/60 s
Photo Format
Video Resolution
4K: 3840×2160@24/25/30/48/50/60/120*fps
FHD: 1920×1080@24/25/30/48/50/60/120*/240*fps* Recording frame rates. The corresponding video plays as a slow-motion video. Slow-motion videos and 4K video recordings only support H.265 encoding.
Video Format
Max Video Bitrate
H.264/H.265: 130 Mbps
* When shooting 4K/120fps video in D-Log M mode with DJI Mini 5 Pro, the video encoding bitrate can reach up to 130Mbps, corresponding to a video stream frame rate of 120fps. However, since slow-motion video files are encapsulated at 30fps, the video length displayed on the player is four times the recording duration, and the bitrate of the parsed encapsulated file is approximately one-fourth of the original encoding bitrate.
Supported File System
Color Mode and Sampling Method
8-bit 4:2:0 (H.264)Normal (FHD/4K):
10-bit 4:2:0 (H.265)HLG/D-Log M:
10-bit 4:2:0 (H.265)
Digital Zoom
4K: 1-3x
FHD: 1-4x
Gimbal
Stabilization
Mechanical Range
Roll: -230° to 95°
Pan: -25° to 25°
Controllable Range
Roll: -180° to 45°
Max Control Speed (tilt)
Angular Vibration Range
Sensing
Sensing Type
Forward
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 72°
Backward
Effective Sensing Speed: Flight Speed ≤ 14 m/s
FOV: Horizontal 90°, Vertical 72°
Lateral
Effective Sensing Speed: Flight Speed ≤ 14 m/s
FOV: Horizontal 90°, Vertical 72°
Upward
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 72°, Left and Right 90°
Downward
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 106°, Left and Right 90°
Operating Environment
Surfaces with discernible patterns and adequate lighting (lux > 1)Downward:
Surfaces with discernible patterns, diffuse reflectivity > 20% (e.g., walls, trees, people), and adequate lighting (lux > 1)
3D Infrared Sensor
Measurement Range (nighttime): 0.5-25 m (reflectivity > 10%)
FOV: Up and Down 60°, Left and Right 60°Downward-Facing Infrared Sensor
Measurement Range: 0.3-8 m (reflectivity > 10%)
FOV: Front and Back 60°, Left and Right 60°
Video Transmission
Video Transmission System
Live View Quality
1080p/30fps, 1080p/60fps
Operating Frequency
5.170-5.250 GHz
5.725-5.850 GHzOperating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
Transmitter Power (EIRP)
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)5.1 GHz:
< 23 dBm (CE)5.8 GHz:
< 33 dBm (FCC)
< 30 dBm (SRRC)
< 14 dBm (CE)
Max Transmission Distance (unobstructed, free of interference)
CE: 10 km
SRRC: 10 km
MIC: 10 kmMeasured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. Always pay attention to RTH reminders in the app during your flight.
Max Transmission Distance (unobstructed, with interference)
Medium Interference: Suburban landscape, approx. 4-10 km
Low Interference: Suburb/Seaside, approx. 10-20 kmMeasured under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Transmission Distance (obstructed, with interference)
Low Interference and Obstructed by Trees: Approx. 0.7-4.5 kmMeasured under FCC standard in obstructed environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Download Speed
10 MB/s (with DJI RC-N3 Remote Controller)
10 MB/s (with DJI RC 2)
Wi-Fi 6: Up to 100 MB/s** Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. Download speeds may vary depending on the actual conditions.
Lowest Latency
Aircraft + Remote Controller: Approx. 120 ms
Depending on the actual environment and mobile device.
Antenna
Wi-Fi
Protocol
Operating Frequency
5.725-5.850 GHz
Transmitter Power (EIRP)
< 20 dBm (FCC/CE/SRRC/MIC)5.8 GHz:
< 26 dBm (FCC/SRRC)
< 14 dBm (CE)
Bluetooth
Protocol
Operating Frequency
Transmitter Power (EIRP)
Battery
Capacity
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 4680 mAh* The Intelligent Flight Battery Plus is not sold in Europe.
Weight
DJI Mini 5 Pro Intelligent Flight Battery Plus*: approx. 117 g* The Intelligent Flight Battery Plus is not sold in Europe.
Nominal Voltage
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 7 V* The Intelligent Flight Battery Plus is not sold in Europe.
Max Charging Voltage
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 8.6 V* The Intelligent Flight Battery Plus is not sold in Europe.
Battery Type
Chemical System
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 33.51 Wh* The Intelligent Flight Battery Plus is not sold in Europe.
Charging Temperature
Charging Time
1 battery can be fully charged in approx. 69 minutes by charging through the drone using the DJI 65W Portable Charger.
1 battery can be fully charged in approx. 46 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
3 batteries can be fully charged in approx. 115 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.DJI Mini 5 Pro Intelligent Flight Battery Plus*:
1 battery can be fully charged in approx. 94 minutes by charging through the drone using the DJI 65W Portable Charger.
1 battery can be fully charged in approx. 56 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
3 batteries can be fully charged in approx. 193 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.Charging time is measured in a test environment with a temperature of 25°C. Actual charging time may increase due to higher ambient temperatures or variations in mains voltage between regions.
* The Intelligent Flight Battery Plus is not sold in Europe.
Battery Charging Hub
Input
Output
Charging Type
DJI Mini 5 Pro Intelligent Flight Battery Plus*: Three batteries charged in sequence* The Intelligent Flight Battery Plus is not sold in Europe.
Compatibility
DJI Mini 5 Pro Intelligent Flight Battery Plus** The Intelligent Flight Battery Plus is not sold in Europe.
Storage
Recommended microSD Cards
-
Lexar Silver plus 64GB A2 V30 microSDXC
Lexar Silver plus 128GB A2 V30 microSDXC
Lexar Silver plus 256GB A2 V30 microSDXC
Lexar Silver plus 512GB A2 V30 microSDXC
Lexar Silver plus 1TB A2 V30 microSDXC
Kingston CANVAS GO! Plus 64GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 128GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 256GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 512GB A2 V30 microSDXC
DJI RC-N3 Remote Controller
Max Operating Time
When charging a mobile device: 1.5 hours
Max Supported Mobile Device Size
Operating Temperature
Charging Temperature
Charging Time
Charging Type
Battery Capacity
Weight
Dimensions
Supported Mobile Device Port Type
Lightning, USB-C, Micro-USB
Using a mobile device with a Micro-USB port requires the DJI RC-N Series RC Cable (Standard Micro USB Connector), which is sold separately.
Video Transmission Operating Frequency
5.170-5.250 GHz
5.725-5.850 GHzOperating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.
Video Transmission Transmitter Power (EIRP)
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)5.1 GHz:
< 23 dBm (CE)5.8 GHz:
< 33 dBm (FCC)
< 14 dBm (CE)
< 30 dBm (SRRC)
